Single cylinder diesel engine
Single cylinder diesel engine, namely the diesel engine with only one cylinder when the number of cylinders is classified. Single cylinder diesel engine is mainly used in agricultural machinery, engineering machinery, automobile industry, shipbuilding machinery, power industry and other fields.

The single-cylinder air-cooled diesel engine is favored by a wide range of users for its features of light weight, small size, simple layout and convenient repair, and is widely used as the supporting power for micro cultivators.

Key Highlights
01. Advanced Combustion Technology
Features Direct Injection (DI) for optimized fuel efficiency and enhanced power output.
02. Wide Power Range
The series offers a versatile selection of power outputs to meet diverse demands.
03. Exceptional Fuel Efficiency
Designed to maximize fuel savings and minimize operational costs.
04. Reliable Performance
With impressive continuous running times, these engines are built for long hours of uninterrupted operation.
05. Flexible Starting Options
Available with both recoil and electric start systems to suit your preferences.
06. Built for Toughness
High compression ratios and robust construction ensure smooth and dependable performance in all conditions.
07. Compact Yet Powerful
Despite their compact design, these engines provide significant power for a variety of tasks.
08. Easy Maintenance
Low lubrication oil capacity and simple maintenance requirements ensure long-term reliability.

Model型号	173F(E)		178F(E)		186FA(E)		188FA(E)		192FC(E)			195F(E)
Type类型	Single-Cylinder,Vertical,4-Stroke Air-Cooled Diesel Engine单缸，垂直，四冲程风冷柴油机
Combustion System燃烧系统	Direct Injection直喷式
Bore×Stroke缸径×行程(mm)	73×59		78×62		86×72		88×75		92×75			95×75
Displacement Capacity排量(cc)	246		296		418		456		498			531
Compression Ratio压缩比	19:01
Engine Speed转速(rpm)	3000	3600	3000	3600	3000	3600	3000	3600	3000	3600		3000	3600
Max Output最大输出功率(kW)	4	4.5	4.1	4.4	6.5	7.1	7.5	8.2	8.8	9.3		9	9.5
Continous Output额定功率(kW)	3.6	4.05	3.7	4	5.9	6.5	7	7.5	8	8.5		8.5	9
Power Output动力输出	Crankshaft or Camshaft(Camshaft PTO rpm is 1/2)曲轴或凸轮轴输出
Starting System启动方式	Recoil or Electric手启动或电启动
Fuel Oil Consumption Rate	<295		<280		<270		<270		<270			<270
燃油消耗率(g/kW.h)
Lube Oil Capacity润滑油容量(L)	0.75		1.1		1.65		1.65		1.65			1.65
Oil Type机油类型	10W/30SAE
Fuel燃料	0#(Summer)or-10#(Winter)Light Diesel Oil O#(夏季)或10#(冬季)轻柴油
Fuel Tank Capacity油箱容量(L)	2.5		3.5		5.5		5.5		5.5			5.5
Continous Running Time	3	2.5	2.5	2	2.5	2	2.5	2	2.5	2		2.5	2
持续运行时间(hr)
Dimension包装尺寸(mm)	410×380×460		495×445×510		515×455×545		515×455×545		515×455×545			515×455×545
Gross weight(Manual/Electric Start)	33/30		40/37		50/48		51/49		54/51			56/53
毛重(手/电启动)(kg)
